Detail ChemSet™ Maxima™ Capsule
ChemSet™ Maxima™ Capsule
Rapid cure Acrylic Resin for extra heavy duty anchoring of threaded studs into solid concrete and stone. For small jobs with few fixings. Ideal for overhead anchoring. One capsule for one hole - no mixing, no mess, no waste. Carbide or diamond drilled holes. Dry, wet or even underwater. Cures in 20 minutes! Balustrade posts, fencing, sheds, structural steel columns, hand rails, seating, machinery hold down
FEATURES & BENEFITS
Non-drip formula for horizontal holes and overhead applications
Glass becomes part of the aggregate
No applicator
Strong bond for extra security
Dry, damp, wet, flooded or underwater
One fixing per capsule - no wasted adhesive
No mixing, no mess, no waste
Rapid 20 minute cure ( at 20° C)
INSTALLATION GUIDE
Installation in Solid Concrete
1. Drill or core hole to specified diameter and depth
2. Remove dust and debris by brushing and blowing 3 times each ( If hole is wet or flooded, brush only)
3. Insert capsule into hole
4. Fit socket into drill and use to rotate and drive a ChemSet™ Anchor Stud into the hole
5. The stud rotation will mix the capsule contents
6. Wait until adhesive has fully cured before loading ( see Loading Time chart bel
